| Nominal Capacity | 1500mAh |
| Battery discharged at continuous current 1mA until voltage reaches cut-off voltage 2.0V at ambient temperature 23±2℃ |
| Nominal Voltage | 6.0 V |
| Maximum Continuous Current | 1500mA |
| Battery with minimum 50% rated capacity discharged at ambient temperature 23±2℃ |
| Maximum Pulse Discharge Current | 3000mA |
| Battery with minimum 50% rated capacity discharged at max pulse for 3 seconds after 27seconds break. Ambient temperature 23±2℃ |
| Storage Condition | Temperature ≤ 30℃ Humidity ≤ 75%RH |
| Operating Temperature | -40℃ to +85℃ |
| Battery Dimension | See drawing on pag |
| Max Weight | 45.0g |
| Self-discharge Rate | 2% |
| Max self-discharged rate at ambient temperature 23±2℃ |
| Shelf Life | 10 years |
| Ambient temperature 23±2℃ |
1. Battery Characteristic
We provide the nominal voltage up to 6.0V
The specific energy density of each battery is 200Wh/kg
- Wide Operating Temperature Range
We provide a wide operating temperature range, from -40℃ to +85℃
Under the condition of normal temperature, the battery self -discharge rate of no more than 2% per year
High capacity, stable performance, without passivation
Battery sealing using the fully sealed structure to reduce the leakage of the battery, make the battery can be stored at room temperature for more than 10 years
High safety performance, reliable and environmental friendly
2. Main Applications
Automatic meters (water meter, electric meter, gas meter), conventional meters, etc.
Well pressure meters in high temperature, float meter, logging while drilling (LWD), measure while drilling (MWD), etc.
Cardiac pacemaker, respirator, oxygenator, inspection devices, monitoring devices, infusion pump, etc.
3. Manufacturing Advantages
- It is ok to use advance automatic technology in HCB;
- Cathode is produced by the unique advanced manufacturing process;
- Varity of solutions including high power, high capacity (hermetic & semi sealing), low temperature etc;
- It is workable for us to provide multiple cascade and parallel connecting ways and combining suggestions with HCB customers;
- HCB products are reliable because they have over 10 years storage date.
- The industrial hermetic sealing cell is firstly used by HCB.
4. Company Advantages
- The quality management system in HCB is accord with GB/T19001-2008/ISO9001:2008 standard;
- The Environment Management System in HCB is accord with GB/T24001-2004/ISO14001:2004;
- The drop test is workable of HCB battery;
- HCB can provide the report for safe transport of goods to the customers;
- CE Standard is workable for HCB Battery;
- Rosh Standard is workable for HCB Battery;
- We can provide you with the UL certificate if you need;
5. FAQS of General Safety Instructions
- How about the storage environment of the battery?
The Battery should be stored in dry environment.
- What are you careful with if there are children beside when you use the battery?
Keep battery out of the children. If swallowed, please contact a physician at once.
- What should you do if the children swallow the battery?
Keep battery out of the children. If swallowed, please contact a physician at once.
- What the danger is if the battery is closed to the fire?
They are going to be hot in very short time and it will lead the leakage of gas and toxic materials which may cause a big rupture.
- If the positive and negative polarity of a battery is directly connected, what will happen?
The batteries can’t be short circuit. If positive and negative polarity of a battery is directly connected, this may cause a short circuit and this may lead to toxic materials or gas leakage and/or violent rupture.
- When the batteries are changed, what should you pay attention to?
The batteries of different electrochemical system, grades, or brands can’t be mixed because it would lead toxic material or gas leakage and/or a big rupture.
- What should be followed during the batteries disposal?
Battery disposal method should be in accordance with local and state regulations.
